Product Details:

Strainers are placed in-line with process piping to remove large solid contaminants from the flow. Strainers can be cleaned and reused. It is used in the field of process industry, power industry, Oil & Gas industry, Coal mining industry, Paper-making industry, Sugar-making industry, water & waste management etc.

Applicable Standard
Design Standard: BS 5352, MSS SP-118
Face to face: Factory standard
End Connection: ANSI B16.11, ANSI B1.20.1, ANSI B16.25, ANSI B16.5
Inspection and Test: API 598

Products Range
Size: 1/2" ~ 2" (DN15 ~ DN50)
Rating: ANSI 150lb ~ 1500lb
Body Materials: Carbon Steel, Stainless Steel, Alloy Steel, Other material under request.
Screen: SS304, SS316

Design Features
Y Pattern
Bolted cover
Drain plug available
Welding flange ends & NPT ends & SW ends available
