Product Details:

The butterfly valve is provided with tripe-eccentric multi-layer metal sealing structure. It is mainly used for regulating flow rate and cutting off or connecting fluid for different mediums in the pipeline in such applications including petroleum, natural gas, chemical industry, metallurgy, power plant, water supply and drainage, etc.

Applicable Standard
Design Standard: API 609, DIN 3354;
Face to Face: API 609, EN 558-1, DIN 3202; ISO 5752;
End Connection: ASME B16.5, ANSI B16.47, EN 1092-1;
Inspection and Test: API 598, DIN 3230;

Products Range
Size: 2" ~ 36" (DN50 ~ DN900)
Rating: ANSI 150lb ~ 600lb
Body Materials: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel.
Operation: Lever, Gear, Electric, Pneumatic, Hydraulic

Design Features
Triple eccentric or double eccentric design
Low Opening & Clothing Torque
Metal to metal seated
Compact design
Blow-out proof shaft
ISO top flange
