Product Details:

Gate Valve is used when the need exist for a device that allows an interruption or cut off the flow of a fluid. It is not recommendable to use Gate Valves for flow modulation as the high velocity of the through may result in erosive damage to the wedge and seats when the valve is partially opened. Under normal operating conditions, the valve should remain either fully open or fully closed. Gate Valve is widely used for the medium of water, steam, air, oil, petroleum and petroleum products, nonaggressive fluids.

Applicable Standard
Design Standard: API 602, BS5352
Socket welded ends: ANSI B16.11
Butt welding ends: ANSI B16.25
Thread ends: ANSI B1.20.1
Inspection and Test: API 598

Products Range
Size: 1/2" ~ 2"(DN15 ~ DN50)
Rating: 800lbs, 900lbs ~ 2500lbs
Body Materials: A105,LF2,F9,F11,F22,F304,F304L,F316,F316L,F321,F51 etc.
Operation: Hand wheel

Design Features
Solid wedge
Outside screw & Yoke (OS & Y)
Standard or Full Port
Full die forged structure
Bolted Bonnet, Welded Bonnet or pressure seal options
